Used Flottweg decanter Z5E-4/454
Different Parameters, Different Price.
Our staff will give you the most suitable quote.
- Type: Z53-4/454
- Manufacturer: Flottweg
- Description: Two-Phase-Decanters
- Bowl diameter: 530
- L/D ratio: Extended
- Material: Stainless steel
- Liquid discharge: Gravity discharge
- Bowl design: Steep angle design
- Year: 2007
Introduction
The Flottweg Z5E-4/454 belongs to the Flottweg Z5E series of small horizontal screw centrifuges, designed for medium to low processing capacity and high-precision separation scenarios:
It adopts “long diameter ratio optimization design”, balancing separation efficiency and equipment compactness;
The screw configuration is “adjustable differential speed + wear-resistant bushing”, suitable for abrasive materials, with strong operational stability;
It supports “solid-liquid two-phase separation”, and in some scenarios, it can achieve preliminary enrichment of the light phase liquid;
The body is compact (dimensions approximately 3800×850×1300 mm), suitable for the space layout of small and medium-sized production lines.
Specification
Category | Details |
Equipment Type | Decanter Centrifuge, Model Z5E-4/454 |
Serial Number & Year of Manufacture | Serial No. 014.005.11, Manufactured in 2007 |
Place of Origin | Germany (Manufacturer: Flottweg GmbH & Co. KGAA, Wiesbaden) |
Decanter Type | Two-Phase Decanter |
Bowl Diameter | 530 mm |
L/D Ratio | 4.0 |
Material | Stainless steel |
Liquid Discharge | Gravity discharge |
Bowl Design | Step angle design |
Core Bowl Parameters | Max speed: 3500 min⁻¹; Separation factor: 2000 G |
Material Parameters | Max sediment density: 1.6 kg/dm³; Temperature range: 0~100°C |
Drive Configuration | Main drive motor: 22~30 kW; Screw drive motor: 7.5~11 kW |
Specific Application Environments
This model is mainly suitable for separation scenarios involving small-scale and high-value materials:
Food Processing: Separation of pulp from juice/jam, solid-liquid separation in plant protein extraction;
Light Industry: Fiber recovery in the mid-stage of paper production, dehydration and volume reduction of printing and dyeing sludge;
Chemical / Pharmaceutical: Solid-liquid separation of fine chemical intermediates, pre-treatment of pharmaceutical fermentation liquid;
Municipal / Environmental Protection: Sludge dehydration in small-scale sewage treatment plants (daily sewage treatment capacity ≤ 50,000 m³)
